NOMINAL FORCE
25t
CHARACTERISTICS
Telescopic three piece zinc plated pump handle.
Rotatory pump socket. It can be operated from any position.
Extension screw provides added lifting height.
Quick and easy maintenance.
Safety oil by-pass system prevents the ram from being over extended and causing damage to the cylicnder.
Pump handle can be locked.
Rotatory carring handle keeps retracted telescopic lever.
We also supply jacks fitted with a pressure gauge always based on a minimum batch. The base, pressure cylinder and oil deposit form one integralpart and provide more strength and safety to the jacks.
Any pressure loads produced by the vehicle axle tilting are absorbed as the piston never comes into contact with the cylinder. Therefore the jack will not be damaged even if the vehicle tilts.
SECURITY
- Safety Overload Valve
- Hydraulic stroke limitation
VIDEO
DRAWING
TECHNICAL SHEET
Capacity (t) | A | B | C | D | Weight (kg) | Reference |
---|---|---|---|---|---|---|
25 | 242 | 150 | 75 | 467 | 14.5 | BR25 |
